BEP 778-ANL BEP Pro-Installer Fuse Holder ANL 300A
SKU: 002812
In Stock
The BEP Pro-Installer Fuse Holder ANL 300A offers superior circuit protection for high-capacity loads (35-300A). With easy fuse replacement, durable construction, and compatibility with 8mm or 10mm ANL fuses, it's ideal for onboard power electronics and wiring protection.
£22.99
ex VAT £19.16
-
Description
BEP Pro-Installer Fuse Holder ANL 300A These ANL fuse holders offer unparalleled circuit protection choice for both the installer and end-user. The innovative Through-Panel fuse holder (8-93522) provides superior access for fuse inspection and replacement. Small electrical loads are catered for with the compact 8-93520 unit while additional cable security and highest capacity is provided by the 8-93521, featuring additional studs for separate clamping of cables or link bars.
Specifications:
- Cable connection studs: Shared 8mm (5/16″) on 8-93520
- Fuse mounting studs: 8mm (5/16″)
- Double washers allow any ANL fuse brand to be fitted
- Fuse type: ANL or ANN (fast blow)
- Swinging fuse style allows changing fuse without removal of fastening nuts
- Amperage: determined by fuse sizing, 8-93520 (35-300A)
- 50 VDC (or determined by fuse fitted)
Providing high-capacity fusing, fast response and very high interrupt ratings (ANL up to 6,000 Amps, Class-T up to 20,000 Amps), these fuse holders are ideal for protecting today’s demanding onboard power electronics technology including inverters and battery chargers. They also protect wiring from short circuits. Pro Installer fuse holders’ durable construction allow fuses to run at maximum load.
- Radiused ends improve cable routing options
- ANL: 300 Amp and 750 Amp surface mount options, innovative new 750 Amp through-bulkhead mount holder (Patent pending)
- ANL: for use with 5/16″ (8mm) or 3/8″ (10mm) ANL fuses
-
