£389.49

The Rutland 504 is a super compact turbine that is great for using wind power for trickle charging. You can be sure that when you arrive on board your batteries will be well charged up and ready for your appliances. Even whilst sailing the Rutland 504 powers on.





Quantity

SKU: 002754 Category:

Marlec Rutland 504 Windcharger 12V CA-11/46

504 Wind Generator (Previously Rutland 503) – Ideal for coastal sailing vessels and weekend users up to 10m.

The Rutland 504 features a unique safety turbine and low friction 3 phase generator which starts at just 5 knots and gives smooth, quiet output.

The sleek profile & conical nose better directs the wind to the aerofoil blades and the tail fin gives good orientation to the wind.

Features

  • High quality robust marine construction
  • 510mm fan diameter, turning radius 255mm
  • Requires 37mm ID Tube mounting pole
  • Weight: 3.85kg
  • Easy to install
Read More...

Description

504 Wind Generator (Previously Rutland 503) – Ideal for coastal sailing vessels and weekend users up to 10m.

The Rutland 504 features a unique safety turbine and low friction 3 phase generator which starts at just 5 knots and gives smooth, quiet output.

The sleek profile & conical nose better directs the wind to the aerofoil blades and the tail fin gives good orientation to the wind.

Features

  • High quality robust marine construction
  • 510mm fan diameter, turning radius 255mm
  • Requires 37mm ID Tube mounting pole
  • Weight: 3.85kg
  • Easy to install
Cut in Windspeed 3 m/s
Output Voltages Available (Nominal) 12V
Power / Current Ratings:
 5m/s     10knots  3W(0.2A)
 11m/s   21knots  29W(2.1A)
 15m/s   29knots  48W(3.4A)
Packed Weight & Dimensions 6 Kg 550x550x260mm
Generator Type Low friction 3 phase, brushless
Yaw Rotation Slipring for 360° free rotation. Low brush wear.
Governing Devices None
Turbine Diameter 510 mm
Turning Radius 304 mm
Net Weight 3.5 kg
