Merlin Equipment 01-8040 Pure Sinewave Invertor 2000w 12v

DC to AC inverters simply and silently convert 12 or 24V DC battery power to 230V AC mains electricity.

Merlin introduced the first switch-mode DC to AC inverter range 25 years ago. Since then we have engineered inverters into thousands of ambulances, specialist vehicles and yachts. Our current Kisae range of inverters is the perfect combination of reliability, performance and price.

• All units develop Pure-Sinewave output for use with all electrical appliances
• High surge capability for starting inductive loads and those with electrical motors (such as vacuum cleaners and pumps)
• Available from 400-2000 watt outputs, 12 and 24V
• High quality design and manufacture processes from known factories
• European e-mark and CE certification

Fact sheets. Copy and paste into browser for information.

https://www.merlinequipment.com/wp-content/uploads/2018/03/Merlin-Kisae-400-2000w-Inverter-4.pdf

https://www.merlinequipment.com/wp-content/uploads/2018/03/Inverter-Fact-Sheet-2.pdf

• Pure Sinewave Output
• 2000 watt output
• UK Socket (note: picture shows Japanese socket)

• USB Charger Output
• Digital Display
• Remote Panel Socket
• Overload, overheat and short-circuit protection
• Compact & Lightweight
• European “e-mark” & CE certification
• Easy to install and use
• Remote panels available

Specifications:

• Continuous output: 2000w
• 5 Minute Rating: 2500w
• Surge rating: 4000w
• Input Voltage:  10.5 – 15.5 VDC
• Output Voltage: 230V AC (+/-5%), 50Hz (+/- 0.01Hz)
• Low battery cut off: Yes, visual and audible warning then unit shut-down
• Overload Protection: Yes, visual and audible warning then unit shut-down
• Dimensions (LxWxH) in mm:  240x420x115
• Weight: 5.5kg
