Oceanflex Single Core Tinned Thin Wall Cable in Red – 10.0mm/10 AWG

Oceanflex 10.0mm² high temperature thin wall marine grade cable with tinned copper conductors, particularly suited to marine and other environments where plain copper can corrode.

This cable has the same specification as our plain copper thin wall cable, except that the copper conductors have been tinned for protection against corrosion. Thin Wall insulation provides significant weight and volume savings, particularly in large wiring harnesses, and the hard grade insulation provides good protection against abrasion damage and cut-through. It has good resistance to fuels (petrol & diesel), oils and dilute acids and a very high resistance to moisture.

Tinned copper single core cable. From the Oceanflex range by Automarine which are manufactured to ISO 6722-1:2011 (class b) 105 degrees C. Tinned Copper Conductors, PVC insulation which saves weight and offers good resistance to abrasion and cut through. Is suitable for both 12v and 24v systems (maximum 60v) The Oceanflex range of Tinned Cables offers excellent resistance to petrol, diesel, lubricating oils and diluted acid, as well as offering very good resistance to moisture. Cable is supplied printed with the specification on the insulation. Conductor specification (mm) 80/0.40. Conductor cross section 10mm². Supplied in Red, to the length you require. As with all cables from Automarine, this is manufactured in the UK for your peace of mind, and safety.

• Manufactured to: ISO 6722-1:2011 (Class B)
• Voltage rating: suitable for 12V & 24V systems (60V max.)
• Nominal current rating: 70A
• Maximum loading: 840W@12V,  1680W@24V
• No./size of conductors: 80/0.40mm
• Conductor cross section: 10.0mm²
• Maximum overall cable diameter: 6.0mm
• Resistance per m at 20°C: 0.00185 Ω
• Conductor material: Tinned copper
• Insulation material: PVC (hard grade)
• Working temperature range: -40°C to +105°C  (with brief excursions up to +120°C )
