£59.99 Each

Whale SS5212 Supersub Bilge Pump 650GPH 12v

Quantity

SKU: 006752 Category:

Whale SS5212 Supersub Bilge Pump 650GPH 12v

The SS5212 Supersub Smart Bilge by Whale, runs on a 12V system. It is part of the original award winning Whale low profile narrow automatic submersible electric bilge pumps, which have been proven for over 20 years. The Intelligent Control system automatically senses Bilge water level, and switches itself on and off when appropriate. It offers a multitude of features, which include: being retrofittable, is able to be fitted in confined areas on board including under engines or cockpit floors. It includes an easy to fit angled mounting bracket, along with the ability to be fitted deep in the Bilge, where other pumps cannot reach. It does not require a seperate bilge switch, is not affected by wave motion and is able to be manually overridden. Can safely be used with fresh or salt water. The spec for this pump are as follows: Open flow rate 650GPH (40 litres/min) It draws 3.2 Amps of current. Maximum discharge Head 3 metres. Hose connectors 19mm.

Installation Instructions

Data Sheet

Read More...

Description

The SS5212 Supersub Smart Bilge by Whale, runs on a 12V system. It is part of the original award winning Whale low profile narrow automatic submersible electric bilge pumps, which have been proven for over 20 years. The Intelligent Control system automatically senses Bilge water level, and switches itself on and off when appropriate. It offers a multitude of features, which include: being retrofittable, is able to be fitted in confined areas on board including under engines or cockpit floors. It includes an easy to fit angled mounting bracket, along with the ability to be fitted deep in the Bilge, where other pumps cannot reach. It does not require a seperate bilge switch, is not affected by wave motion and is able to be manually overridden. Can safely be used with fresh or salt water. The spec for this pump are as follows: Open flow rate 650GPH (40 litres/min) It draws 3.2 Amps of current. Maximum discharge Head 3 metres. Hose connectors 19mm.

Installation Instructions

Data Sheet

Additional information

Brand

Whale

Brand Whale
Automatic Bilge Pumps Yes
Maximum Pump Head 2.3 to 4.27 Metres
Flow Rate 2 Metre Head 1440 LPH (360 US GPH) / 24 LPM (6 US GPM)
Hose Size 19mm / 3/4″
Inlet Outlet Port Size 19mm (3/4”)
Maximum Recommended Head 3 Metres (9.8 Feet)
Model SS5212
Voltage Description 12V DC
Amps Description 3A at 12V, 3.4A at 13.6V
Length Cable: 1 Meter (3.2 feet)
Height Description 54mm (2-1/8″)
Width 212mm (8-3/8″)
Depth 75mm (2-15/16″)
Fuse 5A
Flow Rate Description 2460 LPH (650 US GPH) / 41 LPM (10 US GPM)
Approvals ISO8849 marine (bilge pump) standards, ISO15083 marine (bilge pumping systems) standards, Ignition Protected AYBC & USCG standards, CE Certified 89/336/EEC EMC compliant
Flow Rate 1 Metre Head 2081 LPH (550 US GPH) / 34 LPM (9 US GPM)
Warranty 1 Year
Country of Origin United Kingdom
